Dispensing

Features

1. Time of each injection controlled by timer, dispensing at regular time and quantity to ensure consistency.
2. Select which nozzles, what injection time and pressure, each injection time and quantity can be changed.
3. Dispensing controller can be used to inject liquid or paste, including epoxy resin, solder, silica gel, soldering fluid and etc.
4. Pedal switch and manual control modes available, manual modes are more suitable for stand-up staff.
5. Various barrels, nozzles and spares are available.

Dispensing modes: 16 modes available
Dispensing time: 0.01-99.99 seconds
Time interval: 0.1-9.9 seconds
Repeat stability: ±0.05%
Dimensions: 238(L)*150(W)*60(H)mm
Weight: ~ 1.7kg
Inner voltage: AC 24V
Min injection dosage: 0.01ml
Input air pressure: 0.25-0.7MPa(2.5-7kg)
Output air pressure: 0.01-0.7MPa(1-7kg)
