Electrolube DCR Silicone Conformal Coat, Red,1L

Electrolube DCR Silicone Conformal Coat, Red,1L PRODUCT: ELDCR01L
Electrolube DCR Silicone Conformal Coat, Red,1L
Request a quote
Unit: 0
Arriving Soon: 0
Available Now: 0
Availablity: Delivery Usually 5-7 Days - Contact Us For Updated Pricing and Availablity
Electrolube SCC3 Conformal Coating - 1 Litre Red Coloured

NLA

DCR is a specialist red conformal coating, designed to conceal the PCB design while offering excellent protection. Based on a Modified Alkyd it has been formulated to meet the highest defence standards in both Europe and the United States and is also resistant to many solvents used in the aerospace and automotive industries. DCR can be sprayed, dipped or brushed, for full product details including test results please refer to the TDS below. If you still require further information please don't hesitate to get in touch.
Red opaque coating provides camouflage of PCB design
High chemical and solvent resistance when heat cured
Extremely wide operating temperature range
Resistant to many solvents used within aerospace and automotive industries
Cured coating can be removed with Electrolube Conformal Coating Remover Gel (CCRG)
RoHS-2 Compliant
UL746C-QMJU2
Meets IPC-CC-830

DCR
Modified Alkyd Conformal Coating (SCC3)
DCR is a flexible, red opaque version of DCA specifically designed for the protection of electronic circuitry. It
has been formulated to meet the highest defence standards in both Europe and the United States.
Red opaque coating provides camouflage of PCB design
Heat-cured coating is resistant to many solvents used within aerospace and automotive industries
Suitable for use at temperature extremes; very wide operating temperature range
Can be reworked using specialist removal product, Electrolube CCRG
Approvals RoHS-2 Compliant (2011/65/EU): Yes
IPC-CC-830: Meets approval
UL746C-QMJU2: Meets approval
Liquid Properties Appearance: Red Opaque
Density @ 20°C (g/ml): 1.08 (Bulk), 0.78 (Aerosol)
VOC Content: 40% Bulk, 61% Aerosol
Flash Point: 27°C (Bulk) <23°C (Aerosol)
Solids content: 60% (Bulk) 39% (Aerosol)
Viscosity @ 20°C (mPa s): 410 - 650 (Bulk)
Touch Dry: 50 - 55 minutes
Recommended Curing Schedule*: 2 Hours @ 20°C followed by:
2 - 24 Hours @ 90°C to 120°C
*(Maximum Solvent Resistance Achieved @ 120°C; Ambient Curing Schedule: 24 Hours @ 20-25°C)
Coverage @ 25µm: 24m2 per litre (Bulk), 3m
2 (200ml Aerosol)
Cured Film Coating Colour: Red Opaque
Operating Temperature Range: -70°C to +200°C
Flammability: Meets UL94 V-1
Thermal Cycling (MIL-1-46058C): Meets approval
Coefficient of Expansion: 85ppm
Dielectric Strength: 90 kV/mm
Dielectric Constant: 4.75 @ 1MHz
Surface Insulation Resistance: 1 x 1015 ?
Dissipation Factor (@ 1MHz, 25°C): 0.044
Moisture Resistance (MIL-1-46058C): Meets approval
