Fraser Gererator IONFIX PRO 60 pos AC

Fraser Gererator IONFIX PRO 60 pos AC PRODUCT: FRAE76015P-AC
Fraser Gererator IONFIX PRO 60  pos AC
Request a quote
Unit: Each
Arriving Soon: 0
Available Now: 0
Availablity: Delivery Usually 5-7 Days - Contact Us For Updated Pricing and Availablity
IONFIX Pro high performance 30 kV and 60 kV static generators deliver 150 W of power. Designed for the most demanding electrostatic charging applications, the IONFIX Pro provides comprehensive controllability, simplicity of use and high reliability.

Positive polarities

Fast rise and fall times for high speed operations
Four high voltage outputs for connecting generator electrodes
Easy to operate keypad with large clear LED displays showing precise running information and fault analysis.
Multiple levels of safety and protection
Industry standard remote interface links with process control/PLC
Simple menu for configuring remote interface and accessing advanced settings
180? display rotation and choice of mounting bracket positions for versatile mounting
Used for temporary bonding in many industrial processes, the IONFIX Pro is ideal for applications such as non-stop winders, laminate work surfaces, chill rollers, interleaving and product separation.

Options

Fieldbus connection

Construction

1.5 mm powder coated steel.

Dimensions

264 x 105.25 x 337 mm (W x H x D). 314.30 mm W including mounting brackets.

Electrical Output

760150: 60 kV max, 150 W, 2.5 mA.
Output voltage adjustable in 0.1 kV steps. Current limit adjustable in 0.01 mA steps. Positive or negative polarity to be specified at time of order.

HV Connections

4 generator electrodes can be connected.

External Control and Monitoring

Remote interface for comprehensive control and monitoring with standard
25-way, D-type connection.

Electrical Input

90 - 250 V AC, 50/60 Hz. 3 A max. IEC 60320 C14 inlet.
2.8 m cable.

Safety

Protected against overload, short-circuit, sparking and mis-wiring.

Environmental

Dry, oil-free location. 0 - 50 °C maximum temperature, 70 % rH non-condensing max. IP20.

Certification

CE.
8007-0577 IONFIX-Pro
