Multicore, 362, 62/36/2, 5C, 0.23mm, LMP, Solder Wire, 250g PRODUCT: MCSMC302
Request a quote
Unit:
250g roll
Arriving Soon:
0
Available Now:
0
Availablity:
Delivery Usually 5-7 Days - Contact Us For Updated Pricing and Availablity
Multicore 362 solid flux leave dry and non-stick residues. In use its odour is typically that of rosin fluxes.
Multicore Loctite is a division of Henkel
Leaded Solder Wire
Low Melting Point (LMP), Slightly lower melting point than standard 60/40 solder
Good wetting on most common surfaces
Formulated to leave pale flux residues and to resist spilling and fuming
Non-corrosive
Fast soldering
Rosin based
Halide activated
Wire Type: Leaded Solder Wire
Melting Point:179°C Melting temperature (tip temperature approximately 299°C)
Alloy: 62% Tin (Sn), 36% Lead (Pb), 2% Silver (Ag) Alloy, 2% silver content prevents leaching and the formation of brittle joints during soldering of silver and gold plated surfaces
Flux: 362 for general work
Flux Type: AS Rosin activated flux
Cores: 5
Wire Size: 0.23mm diameter 28 SWG diameter
Roll Size: 250g
A full description of test methods and detailed test results are available on request.
Alloys: The alloys used for Multicore flux cored solder wires conform to the purity requirements of the common national and international standards. A wide range of wire diameters is available manufactured to close dimensional tolerances. For details refer to document Properties of Alloys used in Cored Solder Wires.
Flux: Multicore 362 solid flux leave dry and non-sticky residues. In use its odour is typically that of rosin fluxes.
