Liquid Ultra -Thin Gap Filler, Blue/White, 400mls PRODUCT: ELGF300

Request a quote

Unit: Each

Arriving Soon: 0

Available Now: 0

Availablity: Delivery Usually 5-7 Days - Contact Us For Updated Pricing and Availablity

Notes
Features & Benefits
Specifications
Data Sheets
Images

GF300 is a two part, liquid silicone based gap filler, which provides excellent thermal performance (4.0 W/m.K) and can be cured at room temperature or accelerated with heat. After curing GF300 forms a low modulus elastomer preventing the 'pump-out phenomenon'.

Soft and compliant for low stress applications
Low viscosity; easy to dispense
High thermal conductivity
Low modulus elastomer, prevents 'pump-out'
RoHS Compliant

Size: 400mls

Base Material: Silicone
Colour Part A: Blue
Colour Part B: White
Part A Viscosity (cps 23°C): 200 000
Part B Viscosity (cps 23°C): 140 000
Mix Ratio: 1:1
Gel Time (25°C): 60 minutes
Cure Time (25 °C): 12 hours
Cure Time (100 °C): 15 minutes

Cured Density (g/ml): 3.0
Thermal Conductivity (W/m.K): 3.0
Colour: Pale Blue
Shore Hardness @ 25ºC: 55 Shore 00
Temperature Range (°C): -50 to 200
Flame Retardancy: Meets UL94 V-0

EGF TDS.
