Effective Ionisers for Anti-Static Control

The very compact, high performance 1265 Single Point Ionisers are suitable for neutralising the static charge on small objects and in confined spaces.

The resistively coupled design produces a concentrated cone of ionised air up to 150 mm in diameter. This is ideal for neutralising static electricity on tape, trim, yarns, optical fibres and other small parts.

Robust stainless steel construction with shockproof operation With Thread and nut
All live parts encapsulated in epoxy resin for protection, reliability and a long life
Optimal performance at a distance of 20 < 50 mm
Wide choice of Fraser 5.5 and 6 kV Power Units with optional remote monitoring
Certified cleanroom compatible to ISO Class 4
Easy to install and maintain, the 1265 Single Point Ioniser is frequently used to ionise the air from air jets and nozzles.

Construction :Stainless steel body with PTFE insulation and nylon cable gland.

Cable :Hi-Flex 30 kV screened cable with 70 mm bend diameter. Standard length is 2 m - longer lengths can be specified at time of order (subject to maximum load on power unit).

Safety :100 Mohm resistance in series with HV for shockless operation.

Power Unit :Use with Fraser 5.5 kV and 6 kV Power Units.

Environmental :60 °C maximum temperature. 70 % rH non-condensing max.

Certification :CE.

1260_1265 TDS
