Effective Ionisers for Anti-Static Control

The compact 4800 is the most powerful DC ionised air nozzle available - in both ionisation performance and cleaning capability.

The 4800 DC Ionised Air Nozzle sets new standards in industrial static control technology, with powerful performance and all the advantages of advanced electronics integrated into the compact body. The 4800 DC is powered by 24 V DC.

The 4800 DC is the most powerful ionised air nozzle available. It provides static neutralisation faster than any competitive product and is about 50 % more powerful than our popular 4510 Ionised Air Nozzle. The flat nozzle produces intense air flow, transporting ionised air at high speed for optimal cleaning and blow-off capability.

High cleaning thrust is achieved at lower air pressure, reducing air consumption and noise
Use at close range for maximum thrust optimal cleaning distance typically 50 to 100 mm
All electronics fully encapsulated for protection and reliability
Tungsten emitters guarantee a long life
LED on body gives operational status and whether bar needs cleaning
Remote on/off switching with standby plus signal for operational status
The 4800 DC Ionised Air Nozzle can be used in dust removal, cleaning and static neutralisation applications throughout industry.

This Flat Ioniser air nozzle needs a FRA3024PSU power supply

Click for power supply

Construction Static Eliminator: PVC body, epoxy resin encapsulant, tungsten emitters.
Nozzle: aluminium.

Dimensions 80 x 51 x 33 mm (L x W x D) excluding connectors. Operational Length: 47 mm.

Weight Static Eliminator 100 g,
Nozzle 60 g (excluding connectors).

Output Voltage +/- 7 kV supply integrated inside Ioniser.

Remote Monitor / Local Status Indication

Signals available: ‘OK’, ‘Clean Me’, ‘Fault’ and ‘Standby’. Uses 24 V supply to send signal from the ioniser to the PLC or other destination. Outputs compatible with IEC 61131-2 Type 3 PLC inputs. Signal protected against short circuit or miswiring. Bi-colour LED on ioniser body for local status indication.

Electrical Input 24 V DC (21 , 28 V). Maximum current 0.25 A. M8 connector.


Air Supply Air Fitting: 6 mm OD push fit.
Air Consumption: 300 l/min @ 2 Bar.
Blowing Force: 2.4 N @ 2 Bar.

Environmental 0 ,55 °C, 70 % rH non-condensing max. IP67.

Certification CE and UL Certified (3024 Ultra-Compact incorporated within 4800 DC).
